MULTITASKING

Okuma Multus U4000-2SWX1500: two turrets (upper 40 ATC – lower 12 station / two spindles / 12.6″ turn OD / 59″ max length / B-Axis  -30° –  +210° / Renishaw Gauging

NACHI SRA210 Robot: 210kg max payload / 2,674mm max reach

LATHES HORIZONTAL (CNC)

Okuma LU4000EX-MY 650: two turrets 24 stations total / 16.9” max dia / 25.6” between centers / Y axis milling 5.5” / 3.58” spindle bore

Okuma LB4000 EX II MY: 16.9” max dia / 59” between centers  / Y milling ± 2.76”/ 5.5” / 3.58” spindle bore

Okuma LB45-MY: 26″ max dia (swing 35.4″) / 160″ between centers / Y axis milling / 10.2″ thru spindle

LATHES VERTICAL (CNC)

OM NeoAlpha 16: 71” swing / 71” turn diameter / 59” max height / 9.4” Ram / live tooling

OM NeoAlpha 20: 90.6” swing / 90.6” turn diameter / 86.6” max height / 9.4” Ram / live tooling

MILLS HORIZONTAL (CNC)

Kuraki AKB-13: 78.75” x 71” Table / 118” X / 79” Y / 63” Z / 28” W / 6 axis / Full rotary table (A and B axis) 6 axis total with Cogsdill contouring

Kuraki KBT-11 WA: 55.12” x 63” Table / 78.75” X / 59” Y / 57.1” Z / 19.7” W / 5 axis / Full rotary table with Cogsdill contouring

Toyoda FA800: HMC 31.5” dual pallets / 53” X / 45” Y & Z / Full rotary tables

OKUMA MA500H: 20″ dual pallets with 6 pallet changer / 27.5″ X / 35.4″ Y / 30.7″ Z / Full rotary tables / Renishaw gauging

MILLS VERTICAL (CNC)

Toyoda FV1680: 69” x 31.5” table / 63” X / 31.5” Y & Z with 400MM 4th axis

Toyoda FV1365: 57” x 25.6” table / 51.2” X 25.6” Y X 23.6” Z

CAD/CAM

Esprit

FACILITIES LIST

Square Footage of Building: 18,000

Crane Capacity: 5, 7.5, and 10 Ton overhead crane / 8 Jig Cranes rated at 1 ton each

Pickup and Delivery Capabilities: 2022 Chevy Colorado ¾ ton / 1 Isuzu NPR 5 ton

Forklifts: 2 forklifts range 2 – 5 ton

INSPECTION EQUIPMENT / TOOL SETTING

Hexagon CMM 96” arm 7 Axis with scanner

FARO CMM 96” arm

EasyMetric: Carbon Fiber inspection equipment up to 2000mm

Zoller 640 tool presetter

Gagemaker Mic Trac 3000: Used for calibration of tools and instruments. 36” capacity

*O.D. Micrometers: 0-36” assorted brands

I.D. Micrometers: 0-52” assorted brands

Thread Gages: Gagemaker and assorted plug and ring gages

Height Gages: 2 Brown & Sharpe 0-18”

Surface Plates: 24” x 34” Grade A / 18” x 24” Grade A / 48” x 144” Grade A

Hardness Testing: 2 King Brinnel

Ultrasonic: T Mike E / Dakota

Bore Scope: 31/4”– 53/4”

*Calipers: 0 –60” assorted brands

MULTITASKING

Okuma LU4000EX-MY 650: two turrets 24 stations total / 430 mm max dia / 650 mm between centers / Y axis milling 140 mm / 91 mm spindle bore

Okuma Multus U4000-2SWX1500: two turrets (upper 40 ATC – lower 12 station / two spindles / 32cm turn OD / 150 cm max length / B-Axis  -30° – +210° / Renishaw Gauging

LATHES HORIZONTAL (CNC)

Okuma LB4000 EX II MY: 430 mm max dia / 1500 mm between centers  / Y milling ± 70 mm / 140 mm / 91 mm spindle bore

Mazak Nexus QT450MY-II: 84 cm swing / 58 cm max DIA / 210 cm between centers / Y milling ± 10 cm / 18.5 cm spindle bore

Mazak Nexus QT350MY: 74.93 cm swing / 41.91 cm max dia / 160.655 cm between centers / Y milling ± 7.62 cm/ 10.16 cm spindle bore

Mazak Powermaster: 386.36 cm swing over bed / 54.991 cm swing over cross slide / 312.42 cm  between centers / 31.75 cm thru spindle

LATHES VERTICAL (CNC)

OM NeoAlpha 16: 180.34 cm swing / 180.34 cm turn diameter / 149.86 cm max height / 23.876 cm Ram / live tooling

OM NeoAlpha 20: 230.124 cm swing / 230.124 cm turn diameter / 219.964 cm max height / 23.876 cm Ram / live tooling

MILLS HORIZONTAL (CNC)

Kuraki AKB-13: 200.025 cm x 180.34 cm Table / 299.72 cm X / 200.66 cm Y / 160.02 cm Z / 71.12 cm W / 6 axis / Full rotary table (A and B axis) 6 axis total with Cogsdill contouring

Kuraki KBT-11 WA: 140 cm x 160.02 cm Table / 200.025 cm X / 149.86 cm Y / 145.034 cm Z / 50.038 cm W / 5 axis / Full rotary table with Cogsdill contouring

Toyoda FA800: HMC 80 cm dual pallets / 134.62 cm X / 114.3 cm Y & Z / Full rotary tables

MILLS VERTICAL (CNC)

Toyoda FV1680: 175.26 cm x 80 cm table / 160.02 cm X / 80 cm Y & Z with 400MM 4th axis

Toyoda FV1365: 144.78 cm x 65 cm table / 130.048 cm X 65.024 cm Y X 59.944 cm Z

CAD/CAM

Esprit

FACILITIES LIST

Square Meters of Building: 1,672.255

Crane Capacity: 5, 7.5, and 10 Ton overhead crane / 8 Jig Cranes rated at 1 ton each

Pickup and Delivery Capabilities: 2022 Chevy Colorado ¾ ton / 1 Isuzu NPR 5 ton

Forklifts: 2 forklifts range 2 – 5 ton

INSPECTION EQUIPMENT / TOOL SETTING

Hexagon CMM 244 cm arm 7 Axis with scanner

FARO CMM 121.92 cm arm

FARO CMM 243.84 cm arm

EasyMetric: Carbon Fiber inspection equipment up to 2000mm

Zoller 640 tool presetter

Gagemaker Mic Trac 3000: Used for calibration of tools and instruments. 91.44 cm capacity.

*O.D. Micrometers: 0-91.44 cm assorted brands

I.D. Micrometers: 0-132.08 cm assorted brands

Thread Gages: Gagemaker and assorted plug and ring gages

Height Gages: 2 Brown & Sharpe 0-45.72 cm

Surface Plates: 60.96 cm x 86.36 cm Grade A / 45.72 cm x 60.96 cm Grade A  / 122 cm x 365 cm Grade A

Hardness Testing: 2 King Brinnel

Ultrasonic: T Mike E / Dakota

Bore Scope: 8.255 cm – 14.605 cm

*Calipers: 0 –152.4 cm assorted brands
